2025 Fox 36 FLOAT 29 Factory Grip X2

SKU: 910-21-340
Price
Regular price €1.349,00
Regular price €1.553,00 Sale price €1.349,00
Save €204
/
  • Free shipping over 160 Euro for delivery within Italy

Fox Racing Shox 36 FLOAT 29 Factory Grip X2

Packed with features to dominate the descents, the Fox 36 answers the call from aggressive all-mountain riders with its gravity-focused GRIP X2 damper.

GRIP X2 is the most tunable, supportive and smoothest descent-focused damper ever created by FOX. Riders reap the benefits of sitting higher in the travel while tires stay glued to the ground, cornering with increased traction. It gives you the confidence to push the limits of downhill and enduro racing, all while reducing overall rider fatigue. GRIP X2 is the winning difference.

Features

  • FLOAT EVOL air spring for that plush Fox Feeling
  • Downhill-oriented GRIP-X2 damping cartridge with high-speed and low-speed compression damping
  • Factory Series models feature genuine Kashima Coat
  • Completely redesigned lowers, for optimal stiffness/weight
  • Air and oil channels in the lower leg.
  • Adjusted fork crown diameter for optically pleasing transition between today's thicker steering tubes and fork crown

Product Specifications

Usage & Design

  • Use: All Mountain, Trail
  • Wheel size: 29"
  • Travel: 150 & 160 mm
  • Spring: Air
  • Damping: GripX2
  • Color: Shiny orange or black
  • Weight: 1940 g (as per manufacturer)

Adjustments

  • Rebound, spring rate by air pressure, GripX2 high & low speed compression, high & low speed rebound
  • High-speed compression: 8 clicks
  • Low-speed compression: 18 clicks
  • High-speed rebound: 8 clicks
  • Low-speed rebound: 16 clicks

Construction

  • Steerer: Tapered 1.5" to 1 1/8", Aluminium
  • Steerer length: 265 mm
  • Upper Tubes: 36 mm, Aluminium (Kashima Coat)
  • Crown: Aluminium
  • Lowers: Magnesium

Mounting & Compatibility

  • Disc brake mount: Post Mount (PM7 - Direct Mount 180 mm)
  • Maximum Rotor Size: 230 mm
  • Drop out: 15x110 mm Thru-Axle
  • Offset: 44 mm

Package Contents

  • 1 x Fox Racing 36 Float 29" Factory GripX2 Boost
  • 1 x Fox Racing Boost Thru Axle KaboltX
  • 3 x Volume Spacers
  • 1 x Star nut

Technologies

GRIP X2 - To create the ultimate descent-focused damper, we sought the level of tunability seen in motocross and supercross racing suspension. Riders reap the benefits of sitting higher in the travel while tires stay glued to the ground. Corner with increased traction and the confidence to push the limits of downhill and enduro racing, all while reducing rider fatigue.

Kashima Coat - Buttery-smooth, Genuine Kashima Coat's distinctive gold color is backed by its high performance attributes - properties that provide an exceptionally smooth feel and extreme durability.

FLOAT Airspring - The FLOAT air spring system is lighter and reduces the force to initiate travel, providing excellent sensitivity and small bump compliance for all riders and pressure settings. Similar to our FLOAT rear shocks, the FLOAT system features positive and negative air springs that automatically equalize during use to give each rider the right pressure balance. The progressiveness of the spring curve can be adjusted via air volume spacers, allowing riders to fine-tune the feel of the air spring.

EVOL - A more linear spring curve gives EVOL forks and shocks plushness off the top, extra mid-stroke support, and more tunable bottom-out progression, allowing riders to tap into the ideal pairing of front and rear-end feel. EVOL increases negative air spring volume, specifically positioned and sized for optimum small bump sensitivity.

Air Volume Spacers - The progressiveness of the FLOAT air spring curve can be adjusted via air volume spacers, allowing riders to fine-tune the feel of the air spring.
